Description
The BRIGHT BETA 40BE Overhead 2-Post Lift is a premium electro-hydraulic vehicle lift engineered for professional automotive workshops, service centers, and repair garages. With a 4,000kg (4 Ton) lifting capacity, this heavy-duty lift is designed to safely handle passenger cars, SUVs, pickups, and light commercial vehicles. Its overhead design provides a completely clear floor between the columns, making it ideal for workshops that require unobstructed movement of tools, transmission jacks, and service equipment.
Built for durability and long-term reliability, the BETA 40BE features 5mm heavy-duty steel columns, a 16mm reinforced base plate, and 14mm thick carriage plates for exceptional structural strength. Reinforced lifting arms resist deformation under heavy loads, while the 115mm steel cable pulley minimizes cable wear for smoother lifting performance. The lift is also equipped with a high-strength fine-tooth safety locking system, a height-limit microswitch, and a quick-change slider block for simplified maintenance and enhanced workshop safety.
Whether you’re performing engine repairs, suspension work, brake servicing, tire replacement, or routine maintenance, the BRIGHT BETA 40BE delivers dependable lifting performance, maximum safety, and professional efficiency for busy automotive workshops.
Key Features
- Heavy-duty 4 Ton (4000kg) lifting capacity
- Electro-hydraulic overhead 2-post lift
- Heavy-duty 5mm steel columns
- Reinforced 16mm base structure
- Extra-long carriage with 14mm steel plates
- Reinforced lifting arms for maximum durability
- Precision fine-tooth safety locking system
- 115mm steel cable pulley for smooth lifting
- Height-limit microswitch for added safety
- Quick-change slider block for easy maintenance
- Foot guardrail for operator protection
- Ideal for professional automotive workshops
Benefits
- Clear floor design improves workshop accessibility
- Safely lifts a wide range of passenger and commercial vehicles
- Heavy-duty construction ensures long service life
- Smooth and stable lifting operation
- Advanced safety features protect technicians and vehicles
- Simplifies maintenance with replaceable slider blocks
- Increases workshop productivity and efficiency
Applications
- Automotive repair workshops
- Vehicle service centers
- Brake and suspension repairs
- Engine and transmission servicing
- Tire replacement
- Vehicle inspections
- Fleet maintenance
- General automotive maintenance
Technical Specifications
| Specification | Details |
|---|---|
| Model | BRIGHT BETA 40BE |
| Lift Type | Overhead 2-Post Lift |
| Lifting Capacity | 4000kg (4 Ton) |
| Maximum Lifting Height | 1900mm |
| Minimum Height | 98mm |
| Lifting Time | 40 Seconds |
| Overall Height | 3705mm |
| Overall Width | 3350mm |
| Distance Between Posts | 2800mm |
| Motor Power | 2.2kW (3HP) |
| Power Supply | 220V |
| Total Weight | 650kg |
Package Includes
- BRIGHT BETA 40BE Overhead 2-Post Lift
- Hydraulic Power Unit
- Lifting Arms
- Safety Locking System
- Installation Hardware
- User Manual
