Description

The ELA320 Intelligent Digital Power Supply is a professional automotive power support and electrical maintenance device designed for both new energy vehicles (EVs) and conventional fuel vehicles. It is specially developed for maintenance testing of electrical components, vehicle diagnostics, ECU programming, and stable workshop power applications.

The system features independent high-voltage and low-voltage modules, allowing technicians to manage, maintain, and monitor each power system separately. The independently protected outputs ensure that the high-voltage and low-voltage circuits operate without interference, improving safety, reliability, and testing accuracy during maintenance procedures.

The ELA320 supports:

• High Voltage Output:
  • DC 250V ~ 750V
  • Current: 0 ~ 5A
• Low Voltage Output:
  • DC 12V / 24V
  • Current: 1A

For enhanced safety, the device includes separate protection systems for the input circuit, high-voltage output circuit, and low-voltage output circuit. It can accurately detect and protect against faults such as:

• Undervoltage
• Overvoltage
• Overcurrent
• Short circuit

The ELA320 also supports intelligent protection alarms for:

• Reverse polarity connection
• Current limiting
• Short-circuit overcurrent
• Overtemperature
• Overvoltage
• Undervoltage

To ensure stable long-term performance, the device is equipped with a built-in cooling fan featuring intelligent temperature control, helping maintain safe operating temperatures during continuous workshop use.

Designed for professional automotive workshops, EV repair centers, and diagnostic technicians, the ELA320 Intelligent Digital Power Supply is an essential solution for safe, stable, and efficient electrical system maintenance.

Features

• Suitable for EVs and fuel vehicles
• Electrical component maintenance testing
• Independent high-voltage and low-voltage modules
• Separate monitoring and protection systems
• High-voltage output:
  • DC 250V ~ 750V
  • 0 ~ 5A
• Low-voltage output:
  • DC 12V / 24V
  • 1A
• Independent circuit protection design
• Detects:
  • Undervoltage
  • Overvoltage
  • Overcurrent
  • Short circuit
• Intelligent protection alarms
• Reverse polarity protection
• Overtemperature protection
• Built-in intelligent cooling fan
• Stable and reliable workshop performance
